Waterproof 10 By 10 Double Decker Tents With UV Resistant White PVC Roof Cover
Applications :
20 By 30m Waterproof PVC Roof Cover Double Decker With Solid ABS Wall System can be widely used for party , wedding , catering , promotion and any other activities.
And our Tent has a lot of accessories for your reference, such as the glass wall system , glass door , aluminum staircase and ect to make your events more special and attractive.
| Type | Span Width | Bay Distance | Eave Height | Ridge Height | First Floor Height | Main Profile |
| DDS | 10m/32.8' | 5m/16.4' | 6.75m | 8.5m | 3.21m | 300x120x5mm |
| DDS | 15m/49.2' | 5m/16.4' | 6.75m | 9.34m | 3.21m | 300x120x5mm |
| DDS | 20m/65.6' | 5m/16.4' | 6.75m | 10.17m | 3.21m | 300x120x5mm |
| DDS | 25m/82' | 5m/16.4' | 6.75m | 11m | 3.21m | 300x120x5mm |
| DDS | 30m/98.4' | 5m/16.4' | 6.75m | 11.75m | 3.21m | 300x120x5mm |
| DDS | 40m/131.2' | 5m/16.4' | 6.75m | 13.5m | 3.21m | 300x120x5mm |
| ADDS | 15m/49.2' | 5m/16.4' | 6.75m | 8.6m | 3.21m | 300x120x5mm |
| ADDS | 20m/65.6' | 5m/16.4' | 6.75m | 9.43m | 3.21m | 300x120x5mm
|
Life Span:
Fabric (cover & sidewalls): 10years if well maintained.
Aluminum frame and galvanized connectors: 20years if well maintained
Certificates:
1)ISO 9001: 2008 quality control standard
2)Exclusive Tent Supplier for international sports games like the Asian Games 2011, Shenzhen Universiade, Canton Fair since 2003
3)China Association for Exhibition Centers
Optional accessories Double Decker Tent :
covers: Colourful cover, transparent cover, inflatable roof cover
windows: Dome or square clear PVC windows, mesh window, glass window for glass wall
wooden flooring system: VIP cassette flooring, simple cassette flooring
doors: Double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
fixing methods: Ground anchors, weight plate, expandable bolts
other optional items: Table, chair, lighting, AC, carpet, installation tools etc.
Structure :
)RSXOHU0V(M.png)
1. Frame struss: hard pressed extruded aluminium 6061/T6(15HW) which can last more than 20 years.
2. Fabric cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
3. Connector: strong hot-dip galvanized steel
4. Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
5. Wind load: max. 100km/h (can be reinforced)
6. Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design)
7. Easy to be assembled and dismantled, movable.
8. No pole inside, 100% available interior space
Fxing Methods
1) If it is concrete ground, pls use the expandable bolts.
2) If it is tarmac ground or grass ground or sand ground or other soft grounds, pls use the steel anchors;
3) If it is marble or tile ground or other kind indestructible grounds, pls use the weight plates system;
4) If you will make the concrete bases to fix the tent, pls use the embeded bolts M24x500mm.
Packages:
1. aluminum frame packed in membrane film
2. hardware packed in solid carton box
3. roof and sidewall in professional PVC carry bag
