Fire Retardant Tents For Outdoor Events Marquees , Clear Span 60 By 100 Tent
Description
The clear span of the Huge Hall tent is 40m, 50m, 60m and the main profile size is 400x120x5mm. This tent is a modular structure that can be increased or decreased in bay distance of 5m according to the clients’ requirements. The main frameworks (upright support and roof beam) are manufactured with high impact extruded anodized aluminum (6061/T6). The PVC covers use PVC-coated polyester textile and flame retardance which is based on the European standard din 4102b1, M2.
There are also many different styles sand shapes like square, hexagonal, octagonal, decagonal, dodecagonal, and double decker. All clear span big ten structures are available with a complete range of accessories. These accessories include sidewalls with clear windows, ground anchors, weight plate, lining, glass wall system, and ABS hard wall system.
Specifications
| Model | Span Width | Bay Distance | Eave Height | Ridge Height | Main Profile |
| HH | 50m | 5m | 5.88m | 13m | 400x120x6mm(4-channel) |
| HH | 60m | 5m | 5.88m | 14.6m | 400x120x6mm(4-channel) |
| | | | | | |
| The length can be extended by 5m bay such as 15m,20m,30m,40m...Customized size or shape is available. |
Framework: hard pressed extruded aluminum 6061/T6(15HW) which can last more than 20 years
Fabric Cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
Connector: strong hot-dip galvanized steel
Allowed Temperature Condition: -30 degree Celsius~+70 degree Celsius
Wind Loading: max. 100km/h (can be reinforced)
Snow Loading: 30kg/sqm (snow can't stay if use big degree roof pitch design)
Easy to be assembled and dismantled, movable. No pole inside, 100% available interior space.
Fixing Methods
Applications
Widely used for parties, weddings, events, celebrations, sports, trade shows, warehouse, Hajj, conferences, cafe shops, restaurants, corporate events, etc.
Accessories
Covers: colorful cover, transparent cover, inflatable roof cover
Windows: dome or square clear PVC windows, mesh window, glass window for glass wall
Wooden Flooring System: VIP cassette flooring, simple cassette flooring
Doors: double-wing glass door, single-wing glass door, glass fire door, aluminum door, rolling shutter(automatic or manual)
Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
Fixing Methods: ground anchors, weight plate, expandable bolts
Rain Gutters: inner roof beam rain gutter or rain gutter between two similar tents
Optional Items: table, chair, lighting, AC, carpet, installation tools, booth, mobile toilet, etc.
Packing:
Aluminum frame packed in membrane film
Hardware packed in solid carton box
Roof and sidewall in professional PVC carry bag
Customized packing is available
